Features
The distinctive T-shape chimney style hood offers a modern touch with powerful ventilation that can match the challenges of any home chef while maintaining a innovative design that fits into almost any kitchen.
CODE READY TECHNOLOGY (CRT)*
CODE READY TECHNOLOGY (CRT)*
With Code Ready Technology (CRT) code compliance has never been easier. CRT allows the installer to set the maximum blower speed to achieve the right level of performance offering another solution to address local codes or make-up air requirements.
WC1 SERIES VOICE ACTIVATED*
WC1 SERIES VOICE ACTIVATED*
These elegant pyramidal and t-style chimney hoods with powerful ventilation can meet the challenges of any home chef while featuring a traditional appearance that fits into practically any kitchen. Quiet operation and bright LED lighting enhance your cooking experience, while the voice activation feature provides hands-free operation of your range hood; control power, fan speed, and lights using only your voice. SmartSense® infrared sensors to monitor the heat coming from your range and then automatically adjusts your hood's fan speed to eliminate heat, CO2, and other cooking effluents.
VOICE ACTIVATION
Voice activation provides hands-free operation of your range hood. Control power, fan speed, and lights using only your voice.
DELAY OFF
Delay off feature allows you to continue ventilation for a 10-minute period of time; filter timer ensures you are notified when it's time to change charcoal filters
SMARTSENSE®
SmartSense® uses infrared sensors to monitor the heat coming from your range and then automatically adjusts your hood's fan speed to eliminate heat, CO2, and other cooking effluents.
*Feature images may not reflect actual product.
Specifications
| General | |
|---|---|
| Series Name | WCT1 |
| Blower Included | Yes |
| Airflow | 650 CFM |
| Style | Chimney |
| Color | Stainless Steel |
| Manufacturer Color | Brushed Stainless Steel (Grade 430) |
| Installation | Wall Mount |
| Features | |
| Wi-Fi | Yes |
| Dishwasher-Proof Filters | Yes |
| Technologies |
• Code Ready Technology • Voice Control • SmartSense® • Heat Sentry™ • Wi-Fi Connect |
| Ducting Information |
• Duct Size: 3-1/4" x 10" - rectangular • 6" - round • 8" - round • Duct Direction Vertical or horizontal |
| Speeds | 4-speed Capacitive Touch Slider |
| Additional Information |
• Lighting Type LED Modules (6W per module, color temp 3000K) • 4 Lighting Levels • Lighting Modules Included • Delay Off • Filter Clean Reminder • Hybrid Baffle Filters |
| Accessories | |
| Included | Backdraft Damper |
| Optional |
• ADA Kit HAWRK5 • Recirculation Kit ANKWCPST1 • Universal MUA Damper MD6TU, MD8TU, MD10TU (Requires Fresh Air Inlet) • Fresh Air Inlet 641FA, 643FA, 610FA |
| Dimensions | |
| Class Width | 36" |
| Width | 23.87 inch(es) / 60.64 cm |
| Height | 26 inch(es) / 66.04 cm |
| Depth | 20 inch(es) / 50.8 cm |
| Warranty | |
| Warranty | 5 Year Parts/2 Year Labor |
| Content ID | 741151 |
